3-STAGE SPLIT SHAFT PTO
UARA.801 is the first member of 800 Series. 800 KGM vertical Split Shaft PTO is designed for medium duty trucks with 3-stage. Pump&Roll featured gearbox can be installed as horizontal also. It can provide 100% of input speed. Control system can be pneumatic or mechanic. PTO shaft can be at differential side or cabin side. Second PTO output is the option. In case of double PTO, output is requested, PTO outputs can be shifted independently. PTO outputs can be design with all ISO standard flanges as well as suitable housing for any kind of hydraulic pump. The cooling system can be mount on the gearbox. Engage/Disengage sensor can be installed to observe, if PTO is engaged or not, also RPM counter is another option. In case of drum brake is located on the behind of the main transmission, UARA.801 can be designed with drum brake if requested.
