Power Take-Off UR.15.236

Power Take-Off UR.15.236

Ural Power Take-Off (PTO)

Kozmaksan Ural Power Take OFFs designed for MAZ-YAMZ-URAL Trucks. Kozmaksan URAL PTOs has Single output model, Side Mounting type option and available for UNI&ISO mounting housing or suitable for flange connections.

  • Kozmaksan Product Code: UR.15.236
  • Suitable Main Transmission: JMZ-YAMZ-MAZ 236P - 238
  • Used Trucks
    MAZ-YAMZ-URAL 54326-54323-64226-64229 / RM3 / FAVON / MAZ 5337A2-5093A-5337-53371-5349-5429 MAZ 533702-5433-54331-5551-5559-5551-55513-55514-5552-64225-URAL 4X4-6X6-4320-43202-43206-44202-5423 ZIL 534330-534332-541730-541760 - URAL 5557-4320/10-4320/30-4320/31-4320/41 / MOAZ 4048-75051
Share:

Ural Power Take-Off (PTO)

  • Mounting Type: Side PTO
  • Control Type: Pneumatic&Mechanic
  • Weight: 21 kg / 46.2 lb
  • Sense of Rotation: Same as Engine
  • 1 Year Warranty
  • 10 Years Spare Parts Back Up

Options

  • UNI&ISO&FLANGE Mountings
  • Engage/Disengage Sensor
  • Control Cabel and Lever with Mechanic PTOs

Applications

  • Garbage Truck
  • Crane Truck
  • Dump Truck
Max. Torque 31 KGM / 304 Nm/ 224 LBS-FT
Max. Power 32 kW / 43 HP
Available Internal Ratios 1/0.95
Max. Speed 2000 RPM

Catalogue of UR.15.236

Download
