Power Take-Off MB.5.211

Power Take-Off MB.5.211

Mercedes Power Take-Off (PTO)

Kozmaksan Mercedes Power Take OFFs designed for Mercedes AXOR - ACTROSS trucks on G series main transmissions. Kozmaksan Mercedes PTOs has Single&Double output models, Rear Mounting type option and available for UNI&ISO mounting housing or suitable for flange connections.

  • Kozmaksan Product Code: MB.5.211
  • Suitable Main Transmission: G 125-16 / G 135-16 / G 155-16 / G 180-16 / G 200-16 / G 210-16 / G 240-16 / G 255 / G 210-16 / G 211-16 / G 240 / G 260-16 (17,03) G 260-16 (11,9-15,9-14,2-11,7-9,75) / G 221 - 9 / 16,02 EPS (IdNr: 715561 Code: GD5) / G 181-9 (BRAZIL) / G 141-9 EURO 6 / G 131-9 (16,02-14,57) EPS (IdNr: 715570 Code: NC5) / G 231-16 / G 241 / G 281 / G 330-12 (11,63-16,17)
  • Used Trucks
    1729-1735-1827-1834-1838-1929-1935-2038-2429-2435-2527-2531-2534-2629-2631-2635-2638-3229-3234-3534-3535-1831-1835-1840-1844-1848-1850-1857-1934-1938-1953-2044-2050-2544-2550-2650-2643-2644-3031-3234-3331-3348-4148-3331-3335-3336-3340-3235-3340-2031-2040-2648-3548-3553-3557-3538-2641-3244 ACTROS / 1628-1831-1833-1834-1835-1840-1841-1843-1846-1858-2040-2535-2540-2543-3028-3228-3235-3326-4040-4141-4148-2640-3225-3235-3236-3240-3340-3344-4038-4041-4140-4143-4148-3240-4041-4148-2628-1824-4160 AXOR / Mercedes - Benz Atron 1635-2324-2729 Do Brazil 2012 Blue Tec 5 BRAZIL Gearbox: G 181-9 / SISU TRUCK AROCS 1842

Mercedes Power Take-Off (PTO)

  • Mounting Type: Rear PTO
  • Control Type: Pneumatic
  • Weight: 25 kg / 55 lb
  • Sense of Rotation: Same as Engine Shaft
  • Aluminum Body
  • 1 Year Warranty
  • 10 Years Spare Parts Warranty

Options

  • Engage/Disengage Sensor
  • Second PTO Output

Applications

  • Garbage Truck
  • Crane Truck
  • Dump Truck
Max. Torque 34 KGM / 333 Nm / 245 LBS-FT
Max. Power 35 kW / 46 HP
Available Internal Ratios 1/1.2
Max. Speed 2000 RPM

MB.5.211 Catalogue
