Power Take-Off ISZ.07.MBP6P

Power Take-Off ISZ.07.MBP6P

Isuzu Power Take-Off (PTO)

Kozmaksan Isuzu Power Take OFFs designed for Isuzu trucks. Kozmaksan Isuzu PTOs has Single output model, Side Mounting type option and available for UNI&ISO mounting housing or suitable for flange connections. Depending on PTO output type, torque capacity reaches up to 41 KGM.

  • Kozmaksan Gearbox Code: ISZ.07.MBP6P
  • Suitable Transmission Codes: MBP - 6P / MBF - 5C / MBG - 6P-6Q / MBG- 5A / MBG-5H / MBD-5A,5B,5C,6P / MBJ-5J,6T / MBP-6A, 6R / MBG-5B,5C,5F,5R,6Q,6P,6R (6,378)
  • Used Trucks
    NQR 4.8 TURBO ISUZU / NQR 70 P / FSR / LM524 / FSR 33L / FRR 33H / FTS 33H 7 FSS 33 / EXZ52 / FRR 33L

Isuzu Power Take-Off (PTO)

  • Mounting Type: Left Side PTO
  • Control Type: Pneumatic
  • Weight: 14 kg / 31 lb
  • Sense of Rotation: Opposite of Engine Shaft
  • 2 Years Guarantee
  • 10 Years Spare Parts Back Up

Options

  • UNI & ISO & Flange Mountings
  • Engage/Disengage Sensor
  • Control Cabel and Lever with Mechanic PTOs

Applications

  • Garbage Truck
  • Crane Truck
  • Dump Truck
Max. Torque 41 KGM / 402 Nm / 296 LBS-FT
Max. Power 42 kW / 56 HP
Available Internal Ratios 1/1.09
Max. Speed 2000 RPM

ISZ.07H.MBP6P Catalogue
