Split Shaft PTO - UARA.2005

Split Shaft PTO - UARA.2005

5-STAGE SPLIT SHAFT PTO

UARA.2005 is the highest member of 2000 Series. 2100 KGM vertical  Split Shaft PTO is designed for Heavy Duty trucks with 5-stage to used over-chassis application. Pump&Roll Featured Gearbox can also be installed horizontally. It can provide 100% of input speed. Control system can be pneumatic or mechanic. PTO  shaft can be at differential side or cabin side. Second PTO output is an option.  In case of second PTO, the output is requested, PTO outputs can be shifted independently. PTO outputs can be designed with all ISO standard flanges as well as suitable housing for any kind of hydraulic pump. Lubrication system is built on the Gearbox. Engage/Disengage sensor can be installed to check if PTO is engaged or not, and also RPM counter is another option.

  • 5-Stage Vertical Split Shaft PTO
  • Pump & Roll Feature
  • Built-on Lubrication System
  • Control Type: Pneumatic & Mechanic
  • Mounting Type: Split Shaft
  • Sense of Rotation: Same as Input
  • Weight: 115 kg / 253 lb
  • 1+1 Year Warranty (+1 Year Extended If Control Panel Bought with Unit)
  • 10 Years Spare Part Back Up

Options

  • RPM Counter
  • Engage/Disengage Sensor
  • Cooling System
  • Second PTO Output

Applications

  • Fire Fighting Truck
  • Water Truck
Max Torque 2100 kgm / 20593 Nm / 15188 lb-ft
Max PTO Output Power 185 kW / 248 HP
Available Internal Ratios 1/1.4 - 1/1.2 - 1/1.6 - 1/1.84 - 1/2.25
Required Oil 6 lt / 6.3 qt / 202 oz

Catalogue of UARA.2005
