SPLIT SHAFT POWER TAKE OFF
SPLIT SHAFT PTO
is used in cases where Transmission PTO's are not capable of providing the required power for the superstructure. The split shaft PTO it is located on the truck chassis between the main transmission and differential. These gearboxes are mainly used for Fire Fighting Trucks, Cleaning Combination Trucks, Sweeping Trucks and Road Maintenance Trucks.
SOME DETAILS FOR SPLIT SHAFT POWER TAKE OFF
Depends on Truck Split Shaft PTO can be very various. Split Shaft Units can be vertical or horizontal if Split Shaft PTO is Vertical; it can be 3 axis such as UARA.2002
, 4 axis such as UARA.2006
or 5 axis such as UARA.2005
. When length of the gearbox is increased lubrication system need to be built on the gearbox also. If installation is not done properly, the heating problem can be seen. Even installation is done greatly, in some application superstructure works over and over hours and this is cause of heating. For solution cooling system should be installed on the gearbox.
Although it is optional Split Shaft Units can be controlled by sensors. With Engage & Disengage sensor operator can easily observe if superstructure is on or off and can observe the revolution value with rpm counter sensor. Before selecting Split Shaft PTO, Truck CVW should be checked. Trucks GVW can be from 3 tons to over 30 tons. According to radial force, every truck needs different solutions. When we categorize trucks we see 4 types. Extra Heavy Duty Trucks, Heavy Duty Trucks, Medium Duty Trucks, Light Duty Trucks. Every truck need different solutions and different Split Shat Units
PUMP&ROLL FEATURE: Pump&Roll Feature which means you can make run your superstructure while you drive your truck. It is very intended feature especially for Fire Fighting Truck and Water Truck manufacturer. During drive main gear should not be changed. Kozmaksan Light Duty 400 series(UARA.405 UARA.400 UARA.404 UARA.401), Medium Duty 800 series( UARA.801 UARA.806 UARA.805), Heavy Duty 2000 series (UARA.2002 UARA2006 UARA.2005) units are all have Pump&Roll Feature. For more information please go to “Technical Support”
HOT SHIFT FEATURE: Especially for Vacuum Cleaning Truck, Sewer Cleaning Combination Truck, Water Jetting Truck “Hot Shift Feature” is very desirable feature. With clutch mechanism not necessary to press clutch pedal during engage/disengage process. Kozmaksan Hot Shifted Featured products are UARA.3005 UARA.2400 UARA.450 UARA.240
HYDROSTATIC DRIVE: Typical Pump&Roll Featured Kozmaksan Split Shaft Units are transferring power differential and the equipment during the drive. That means power is divided. The aim of Hydrostatic Drive technology is to transfer movement to the differential even by split shaft unit in full operation with the superstructure. On the other hand, Hydrostatic Drive provides low speed while superstructures needed to be run with high-speed values. Especially Sweeping Trucks, Salt Spreaders, multi-purpose trucks for road maintenance, Airport Firefighting Trucks can be good application for this system. With hydrostatic gearboxes you do not need to use second engine with this system. Thanks to Hydrostatic Drive you can build your truck with lower fund and you will economize fuel expense. Kozmaksan Hydrostatic Gearboxes are UARA.1100 UARA.2501 UARA.865 UARA.860
USAGE OF SPLIT SHAFT POWER TAKE OFF
The most important thing is installation of Split Shaft Units for use the product efficiently. Firstly drum brake of truck should be checked. Some truck has drum brake behind their main transmission. For this application Split Shaft Units needs to build with drum brake system. (resim a)
Split Shaft Units should be used with 75W90 EP or equivalent oil type. Engagement and Disengagement could be both mechanical and pneumatic. During Engaged/Disengaged process, the clutch pedal should be pressed.
The Split Shaft Units are shipped as unoiled! Oil should be filled into the Split Shaft PTO by using the oil filling mechanism, before running the vehicle. The oil filling operation should be made on the ground. The required oil level is the top level shown on the indicator. The oil should be totally clean. You are required to use only the recommended oil. (SAE 80 W 90 EP or equivalent oil) In case of using any oil other than the recommended oil, the vehicle is out of warranty coverage. Maintenance should be made before and after long trips. Maintenance should be made at ground level and when the vehicle is not running. In case the oil level is less than required, oil should be added. Make sure that old oil is totally drained and make sure that you are using recommended (correct) oil. In case of mixing old and new oil; This situation is going to cause damage to components of gearbox ( shaft, gear, bearing etc.)
First oil changing should be made following 250 hours after the Split Shaft Unit has started to run. Oil changing should be made when the oil is cold. Draining could be made by removing the drain plug. In order to accelerate the process, it is recommended to remove the filling plug also. Before restarting, the drain plug is required to be cleaned. Subsequent oil replacements should be made once in every 1000 hours or once a year.
Check for oil leaks periodically. Check for any oil leaks in the area where the vehicle is operated and the surroundings. In case of detecting any oil leaks, prevent oil leaking, add oil if necessary, contact with manufacturer firm KOZANOĞLU KOZMAKSAN
